Welded Mesh with 358 Rebound
Applications
Sports
MUGAs
Schools
Features
Hard to climb
Good delay factor
Good visibility
Cost effective
Ball rebound facility
Specification
Standard heights:
2700mm, 3000mm, 3600mm
Posts:
Angle or box section according to requirement and height.
Mesh:
50 x 50mm (75 x 25mmm on certain heights)
Wire:
3mm or 2.5mm thick (add 5mm for coated thickness)
Rebound Element:
75mm x 12.5mm x 4mm x 1.27m high 358 mesh panels at base of fence secured with 40 x 40 x 5mm angle rails (with or without clamping strips) Mesh butted up or overlapped at posts
Fixings:
Line wires tied to mesh, struts and winding fixings at straining posts
Finish:
Hot Dip Galvanised or PPC coated green or black
Download as PDF here
|
Welded Mesh rebound systems offer a budget alternative to heavier sport systems fences. The materials cost is less but the durability remains high.
|
|
